LENZE-BLE-MESH SOLUTION
LENZE-BLE-MESH is a communication capability for establishing many-to-many (m:m) device transmissions, network coverage and low-power Bluetooth, using a tree topology with nodes that have multiple features of SIG-MESH for the ST17Hxx family of SoCs. network. It does not require a central node and uses publish/subscribe model communication to deploy nodes in a one-to-many or many-to-many manner. Based on this network topology, it can scale up to tens of thousands of nodes, allowing devices to be transmitted in a reliable and secure environment as an IoT solution.
Chip Overview
ST17H63/62 SoC
Bluetooth® 5.2 SoC,supporting Bluetooth® Low Energy,Bluetooth® MESH,Bluetooth Direction Finding
- • ARM® Cortex™-M0 with FPU
- • 512/256KB Flash,138KB SROM
- • 2.4 GHz transceiver
- • High-speed 2 Mbps
- • Bluetooth Low Energy
- • SIG-Mesh Multi-Feature
- • +10 dBm TX Power
- • 128-bit AES
- • UART,SPI,TWI, PDM,I2S,PWM,I2S
- • 12 bit ADC
Technology Highlights
Low power support
Node sleep/wake support
Low-power operation mode
Durable anti-interference
Resistant to 2.4G network stem resistance band management, stable 24 hours of endurance
Stable and easy to configure
Multi-path information transmission
Improved system reliability
Low cost and easy to deploy
No need to purchase expensive gateways
No physical wiring to configure
Mesh Stack Networking
No central gateway required
Fast, low-latency group control
Dual security mechanisms
Support SIG-Mesh standard protocol
Support application layer/network layer security key
Application Areas
Smart Home
Beacons
Smart Light Control
Object Tracking
Excellent Case
